| 產品規格及說明 | |
|---|---|
| 設備品牌：帝龍 | 設備型號：UV-Integrator140 |
| 訂購價格：電話/面議 | 交貨日期：3~30/工作日 |
| 電源:0 | 分辨率:0 |
| 產地:廣東 | 量程范圍:0 |
| 取樣時間:0 | 是否進口:否 |
| 加工定制:否 | 外形尺寸:0（mm） |
| 類型:手持式紫外輻照計 | 是否跨境出口專供貨源:否 |
| 產品標簽：uv能量計uv,德國能量計,integrator,140uv能量計,uv140能量計,140能量計uv,德國uv能量計,integrator140,原裝德國uv能量計,integrator140德國,140能量計uv能量計,integrator140能量計,德國原裝integrator140 | |
| 咨詢熱線：13715339029 | 售后服務：13715339029 |
| 技術咨詢：13715339029 |  QQ咨詢：260200500 |
UV-Integrator 140
The UV-Integrator 140 is a high quality UV measuring instrument. It is used to measure UV energy of different light
sources, especially on printing machines. It was specially designed with a recess in the housing for better handling.
It is ideal to ensure quality control of printing and drying processes.
Big size, heavy duty pass-through Integrator with a diameter of 140 mm. It is reliable and simple to use.
The UV-Integrator 140 is available in six different measuring ranges*:
(Please state upon order)
Item 9.1 UV-Integrator 140, Type 1, Diazo 350 – 460 nm
Item 9.2 UV-Integrator 140, Type 2, UV-A 315 – 400 nm
Item 9.3 UV-Integrator 140, Type 3, UV 250 – 410 nm
Item 9.4 UV-Integrator 140, Type 4, UV-B 280 – 315 nm
Item 9.5 UV-Integrator 140, Type 5, UV-C 230 – 280 nm
Item 9.6 UV-Integrator 140, Type 6, UV-V 395 – 445 nm
*further spectral ranges available upon request
By addition of the incidence of the light quantities during the exposure cycle, relative values are calculated.
Because of uneven radiation distribution of the UV light source and different type of construction of the measuring
devices by different manufacturers, different readings may appear under the same measurement conditions.
Technical Data:
Spectral range: UV 250 – 410 nm
Measuring range: 0 to 5,000 mW/cm2
Display: 6-digit LCD
Display range: 0 to 999,999 mJ/cm2
Power source: long life 3.6 V Lithium Battery
Power consumption: 100 μA
Battery service life: 10,000 hrs
Dimensions: ∅ 5.5” (140 mm) height ½” (13 mm)
Weight: approx. 16 ounce (450 grs.)
Temperature range: 0 to 45° Celsius
Heat protection: Heat shield on back plate
Base Accuracy: ± 5 %
While on the conveyer belt, the UV-Integrator 140 can withstand max. 110° C / 230° F for up to 10 seconds. The
temperature of the housing should not exceed 45° C / 113° F.
Calibration:
In order to keep its full function and precision it is recommended to have re-calibration done once per year. Recalibration will also be necessary after change of battery. Ongoing, PTB traceable calibration with certificate
Warranty:
2 years from the date of purchase, For the German quality battery we guarantee one year
最新德國UV能量計 UV-Integrator140 UV能量計大陸總代 原裝正品 謝絕講價?。?/span>
1、注意識別真假UV能量計
德國UV-Integrator140官方網站：UV-Integrator140
http://www.masxsgy.cn style=”margin-top: 0.0px;margin-bottom: 0.0px;line-height: 1.5;clear: both;color: #333333;font-size: 12.0px;”>在德國UV-DESIGN官方網站可以查詢到真正代理商
2、德國UV-DESIGN官方公布未授權的生產廠家
網址查詢：http://www.masxsgy.cn style=”margin-top: 0.0px;margin-bottom: 0.0px;line-height: 1.5;clear: both;color: #333333;font-size: 12.0px;”>
3、德國UV-DESIGN官方公布高仿產品生產廠家：
http://www.masxsgy.cn style=”margin-top: 0.0px;margin-bottom: 0.0px;line-height: 1.5;clear: both;color: #333333;font-size: 12.0px;”>
兩招小技巧教你識別真假UV能量計
1、每一個原裝的最新UV-Integrator140在機身和校準證書上都有一個藍色標識：Unifare Technology
2、最新原裝UV-Integrator140，德國UV-DESIGN公司的每一個產品機身都有序列號，可以在官方網站查詢是否為真正的原裝產品。
